The MD 9273 Bluetooth TRMS leakage clamp from Metrel

Leakage clamp

Wireless connectivity between a PC, notebook or a mobile device, and a tester is nowadays a must-have feature. Some testers, like the new MD 9273 Bluetooth TRMS leakage clamp with power functions from Metrel, also support connectivity to other testers. A successor to the MD 9272 leakage clamp TRMS meter with power functions, the MD 9273 Bluetooth TRMS leakage clamp boasts the same array of test and measurement functions, but with support for Bluetooth connectivity.

Key features:

  • Operation as a remote current clamp and voltage probe for online measurements of current, voltage, power or harmonics
  • Bluetooth connection to MI 3155 EurotestXD, MI 3152 EurotestXC or MI 3325 MultiServicerXD
  • Inrush current recording with MI 3155 EurotestXD, MI 3152 EurotestXC or MI 3325 MultiServicerXD
  • 128Hz notch filter for cable tracing
  • Online measurements of current, voltage, power, current harmonics and voltage harmonics
  • TRMS: accurate measurements of sinusoidal and non-sinusoidal signals
  • Jaw size: 28mm
  • Shielded jaw: allows the clamp meter to be used in high-EMI environments
  • Accurate: readings of AC current with an accuracy of 0.8% and a base resolution of 0.01mA, and voltage with an accuracy of 0.5% and a base resolution of 0.1V
  • Power: measuring various power parameters (active, reactive, apparent power, power factor, phase displacement)
  • Intelligent loss analysis: complex algorithms detect current losses and suggest possible reasons for them
  • Harmonics: measuring current or voltage harmonic components and percentage values of harmonics up to the 19th
  • THD and PF: dual display allows readings to be displayed along with Total Harmonic Distortion (THD) or Power Factor (PF)
  • Peak value: the peak value of the waveform or crest factor can be displayed
  • MAX/MIN/HOLD mode: displays maximum, minimum, or average measured value
